60227 IEC 01 BV Single-core non-sheathed cable with rigid conductor for general purposes
Construction
(1) Conductors
Number of conductors:1.
The conductors comply with the requirements of lEC 60228:
-class 1 for solid conductors;
-class 2 for stranded conductors.
(2) Insulation
The insulation is polyvinyl chloride compound of type PVC/C applied around the conductor.
Technical Performance
Maximum conductor temperature in normal use: 70°C.
The use of the cable type 60227 lEC 01 comply with lEC 62440, which provides guidance on the safe use of electric cables with a rated voltage not exceeding 450/750 V.
Parameter Table
| 1 | 2 | 3 | 4 | 5 | 6 |
|
Nominal cross- sectional area of conductor mm² |
Class of Conductor IEC 60228 |
Thickness of insulation Specified value mm |
Mean overall diameter |
Minimum insulation resistance at 70°C MΩ · km |
|
|
Lower limit mm |
Upper limit mm |
||||
| 1.5 | 1 | 0.7 | 2.6 | 3.2 | 0.011 |
| 1.5 | 2 | 0.7 | 2.7 | 3.3 | 0.010 |
| 2.5 | 1 | 0.8 | 3.2 | 3.9 | 0.010 |
| 2.5 | 2 | 0.8 | 3.3 | 4 | 0.009 |
| 4 | 1 | 0.8 | 3.6 | 4.4 | 0.00805 |
| 4 | 2 | 0.8 | 3.8 | 4.6 | 0.00707 |
| 6 | 1 | 0.8 | 4.1 | 5 | 0.00700 |
| 6 | 2 | 0.8 | 4.3 | 5.2 | 0.00600 |
| 10 | 1 | 1 | 5.3 | 6.4 | 0.00700 |
| 10 | 2 | 1 | 5.6 | 6.7 | 0.00605 |
| 16 | 2 | 1 | 6.4 | 7.8 | 0.00500 |
| 25 | 2 | 1.2 | 8.1 | 9.7 | 0.00500 |
| 35 | 2 | 1.2 | 9 | 10.9 | 0.00403 |
| 50 | 2 | 1.4 | 10.6 | 12.8 | 0.00403 |
| 70 | 2 | 1.4 | 12.1 | 14.6 | 0.00305 |
| 95 | 2 | 1.6 | 14.1 | 17.1 | 0.00305 |
| 120 | 2 | 1.6 | 15.6 | 18.8 | 0.00302 |
| 150 | 2 | 1.8 | 17 | 21 | 0.00302 |
| 185 | 2 | 2 | 19 | 23 | 0.00302 |
| 240 | 2 | 2.2 | 22 | 26.6 | 0.00302 |
| 300 | 2 | 2.4 | 24.5 | 29.6 | 0.00300 |
| 400 | 2 | 2.6 | 27.5 | 33.2 | 0.00208 |
